Configuring the SMC Software 5-23
1. The Access Server Loader Configuration dialog box displays (Figure 5–16).
On the Clients tab, enter the following information:
Host Name: computer name (Section 5.2.1)
Hardware Addr: from the label on the terminal server (
in Figure 5–17)
IP Addr: 90.0.0.1
Subnet Mask: 255.255.255.0
NOTE: The IP address you enter in the Access Server Loader Configuration
dialog box is the IP address for the terminal server, not for the host.
2. Click OK. The Access Server Loader window displays.
Figure 5–17 Location of Hardware Address Label
PK-1783-00
00 -6 0- 6D -9 3- 57 -C 0
1
