ConsoleWorks 8-17
1. In the left navigation panel select Consoles. The Show Consoles screen
displays.
NOTE: The maximum number of consoles supported by this version of
ConsoleWorks is eight. If the Show Consoles screen lists eight
consoles (not including the ConsoleWorks internal console,
CONWRKS), do not attempt to add a ninth. Instead, you must
delete a console before adding another.
2. At the top of the Show Consoles screen select Add Console. The Add Console
screen displays.
3. From the Type dropdown menu select Telnet. Click the Add Console button.
The Add Telnet Console screen displays (Figure 8–12).
4. Enter the information requested for the console:
a. Enter a name and a description for the console. The console name must
be unique.
b. Select Yes in the Logged list box. In the block to the right of the list box
enter D:\Cwks\Log.
c. In the IP Host block enter 90.0.0.1.
d. In the IP Port block enter a number between 2001 and 2008; the last
digit is the terminal server port to which the console is attached. This
number must be unique for each console.
e. Do not select the Raw Data checkbox.
Continued on page 8-19
