Part Names
For details on the use of each part, refer to the page number indicated in brackets.
W/B (White Balance) button [p. 52]/
IR (Infrared) LIGHT button [p. 35]
SUPER CAT'S EYE switch [p. 35]
Lens hood--------
Zoom lens
Infrared light--------
transmitter [p. 35]/
Remote sensor [p. 43]
GAMMA/BRIGHTER button
[pp. 33,34, 61]
AUTO ON/OFF button
[p. 28]
Stereo microphone
[p.
68
]
Operation button [p. 27]
MENU/DISPLAY button
[p. 27]
Media Selection switch (TAPE/CARD
selection switch) [p. 26]
