Parameters of Commands and Responses
z Read/write data
The following table lists the types of data that can be read from and written to IB Series sensor
amplifiers.
When data is written while the initial reset is being performed, the parameter error will occur
(Error number: 22). When writing data after the initial reset is performed, confirm that the
EEPROM writing result (Data number: 053) shows "1: Normal termination" and then write
data.
Data
No.
Data name
Data
format
*1
No. of
bytes
Attribute
*2
Data range
Default value
001
Zero shift request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform zero shift*
3
002
Zero shift reset request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform zero shift reset*
3
003
Reset request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform reset*
3
004
Error clear request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform error clear *
3
*
4
005
Initial reset request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform initial reset*
3
006
System parameter set request*
5
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform system parameter set*
3
010
Reference light registration
request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform reference light amount
registration
011
Adjust request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform adjust*
3
012
Adjust reset request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform adjust reset*
3
014
Tolerance tuning request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform tolerance tuning*
3
015
2-point tuning HIGH side 1st
request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform 2-point tuning HIGH side 1st
point*
3
016
2-point tuning HIGH side 2nd
request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform 2-point tuning HIGH side
2nd point*
3
017
2-point tuning LOW side 1st
request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform 2-point tuning LOW side 1st
point*
3
018
2-point tuning LOW side 2nd
request
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform 2-point tuning LOW side 2nd
point*
3
019
Measured correction 1st
request*
6
*
7
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform measured correction 1st
point*
3
020
Measured correction 2nd
request*
6
*
7
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform measured correction 2nd
point*
3
026
Logical correction 1st request*
6
*
7
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform logical correction 1st point*
3
027
Logical correction 2nd request*
6
*
7
*
1
R
0 - 1: Last written value
1
W
0
o 1: Perform logical correction 2nd point*
3
Point
Parameters of Commands and Responses
065
HIGH setting value (BANK 0)
±***.** *
8
7
R/W
-999.99 to +999.99
20.00
066
LOW setting value (BANK 0)
±***.** *
8
7
R/W
-999.99 to +999.99
10.00
067
Shift target value (BANK 0)
±***.** *
8
7
R/W
-999.99 to +999.99
0.00
068
HIGH setting value (BANK 1)
±***.** *
8
7
R/W
-999.99 to +999.99
20.00
069
LOW setting value (BANK 1)
±***.** *
8
7
R/W
-999.99 to +999.99
10.00
070
Shift target value (BANK 1)
±***.** *
8
7
R/W
-999.99 to +999.99
0.00
071
HIGH setting value (BANK 2)
±***.** *
8
7
R/W
-999.99 to +999.99
20.00
072
LOW setting value (BANK 2)
±***.** *
8
7
R/W
-999.99 to +999.99
10.00
073
Shift target value (BANK 2)
±***.** *
8
7
R/W
-999.99 to +999.99
0.00
074
HIGH setting value (BANK 3)
±***.** *
8
7
R/W
-999.99 to +999.99
20.00
075
LOW setting value (BANK 3)
±***.** *
8
7
R/W
-999.99 to +999.99
10.00
076
Shift target value (BANK 3)
±***.** *
8
7
R/W
-999.99 to +999.99
0.00
097
Key lock setting
*
1
R/W
0: Disabled
1: Key lock
0
098
Bank setting*
9
*
1
R/W
0: Switch to bank 0
1: Switch to bank 1
2: Switch to bank 2
3: Switch to bank 3
0
099
Timing input*
10
*
1
R/W
0: Timing input OFF
1: Timing input ON
0
100
Laser emission stop input*
10
*
1
R/W
0: Laser emission stop input OFF
1: Laser emission stop input ON
0
104
Sub display's screen
*
1
R/W
0: R.V. value screen
1: Analog output screen
2: HIGH setting value screen
3: LOW setting value screen
4: Shift target value setting screen
0
105
System parameter*
11
**
2
R/W
Main unit: 0 to 9
Expansion unit: 0 to 1
0
106
Tolerance tuning setting width
***.** *
12
6
R/W
0.00 to 999.99
10.00
107
Calibration function
*
1
R/W
0: Do not correct (Initial state)
1: Measured correction
2: Logical correction
0
108
Measured/Logical correction
target 1*
6
*
7
±***.** *
8
7
R/W
-999.99 to +999.99
0.00
109
Measured/Logical correction
target 2*
6
*
7
±***.** *
8
7
R/W
-999.99 to +999.99
100.00
115
Logical correction measured 1*
6
*
7
±***.** *
8
7
R/W
-999.99 to +999.99
0.00
116
Logical correction measured 2*
6
*
7
±***.** *
8
7
R/W
-999.99 to +999.99
100.00
130
Measurement mode*
13
*
1
R/W
0: % mode
1: Dimension mode
0
131
Received/Blocked light mode
*
1
R/W
0: Received light mode
1: Blocked light mode
0
