3-2 I/O Communication
3-14
- DeviceNet Compatible Network Unit DL-DN1 User’s Manual (SK-1000) -
3
Comm
u
nic
a
ti
ng
w
it
h th
e
SK-1
000 Se
ri
es
IN area
n: The first device number assigned to the DL-DN1
The device assignments are the same for all 3-output modes including extended
modes.
5-output mode
OUT area
m: The first device number assigned to the DL-DN1
IN area
n: The first device number assigned to the DL-DN1
The device assignments are the same for all 5-output modes including extended
modes.
Device
(DEC)
Name
Bit 7
Bit 6
...
Bit 1
Bit 0
Bit 15
Bit 14
...
Bit 9
Bit 8
n+7
Setting-value rewrite error
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
n+8
HI setting value (BANK 0)
rewrite complete
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
n+9
LO setting value (BANK 0)
rewrite complete
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
Device
(DEC)
Name
Bit 7
Bit 6
...
Bit 1
Bit 0
Bit 15
Bit 14
...
Bit 9
Bit 8
m+5
Request to rewrite HI set-
ting value (BANK 0)
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
m+6 to 7
HI setting value (BANK 0)
HI setting value to be rewritten
(4-byte signed integer)
m+8
Request to rewrite LO set-
ting value (BANK 0)
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
m+9 to 10
LO setting value (BANK 0)
LO setting value to be rewritten
(4-byte signed integer)
Device
(DEC)
Name
Bit 7
Bit 6
...
Bit 1
Bit0
Bit 15
Bit 14
...
Bit 9
Bit 8
n+11
Setting-value rewrite error
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
n+12
HI setting value (BANK 0)
rewrite complete
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
n+13
LO setting value (BANK 0)
rewrite complete
ID08
ID07
...
ID02
ID01
Reserved
ID15
...
ID10
ID09
