Section 5: Block Writes
29
C1: Starts the program
MOVW1: Downloads the information in K1-K14 into WY17-WY31 (weight controller)
5.6 BLOCK WRITE COMMAND NUMBERS
Block Write Command Number 70: Activate Scale Functions
Byte Definitions Byte
Pos. #
Words
Start Word # Bytes Start Byte
Block Write Number 70 (Hex 46)
Activate by setting remote functions bit to 1 then
reset to 0
TARE = Current Gross Weight
Initiates print on standard RS232
Add current net weight to Total
Clear Peak Hold
Clear Totalizer Accumulator
Zero the Instrument
Enable Zero Tracking (blind unit only)
Reserved for future use
Total Words/Bytes
LSB
MSB
bit 0
bit 1
bit 2
bit 3
bit 4
bit 5
bit 6
bit 7
1
1
0 1
1
1
0
1
Block Write Command Number 71: Force Relay Status
Byte Definitions Byte
Pos. #
Words
Start Word # Bytes Start Byte
Block Write Number 71 (Hex 47)
Activate by setting remote functions bit to 1 then
reset to 0
Relay 8
Relay 7
Relay 6
Relay 5
Relay 4
Relay 3
Relay 2
Relay 1
Total Words/Bytes
LSB
MSB
bit 0
bit 1
bit 2
bit 3
bit 4
bit 5
bit 6
bit 7
1
1
0 1
1
2
0
1
