Section 3: Setup
13
3.3 BLIND UNIT SETUP PROCEDURE
A blind HI 2151 Series Weight Controller is configured without a front panel and keypad.
To set the PROFIBUS station address, a dip switch on the PROFIBUS Interface Card and
the Power & Relay PCB, must be set.
To set the power and relay (Prt # 0535-0427) dipswitches for the PROFIBUS Interface
Card:
1. Disconnect the power cord.
2. Open the panel door.
3. On the Power & Relay Printed Circuit Board (Prt # 0535-0427) there is a dipswitch
S2. (See Fig. 3-4)
Figure 3-4
4. Set the #6 Dipswitch to “on” and the other switches to “off” (See Fig. 3-5)
Figure3-5
