Section 4: Block Reads
25

NOTE: The data in Block Read #32 is not valid for the HI 2151/30WC.
Block Read Data Number 32: Configuration of Standard RS232 Port
Byte Definitions Byte Pos. #
Words
Start Word # Bytes Start Byte
Block Read Number 32 (Hex 20)
Reserved for future use
Reserved for future use
Format of Printout
Print Initiation (0 = Continuous, 1 =Altered
print)
Set point, Dead band and Preact
Rate-of-Change
Tare Weight
Net Weight
Gross Weight
Print Initiation (0 = Continuous, 1 = Altered
print)
Reserved for future use (must be set to 0)
Baud Rate (0 = 600, 1 = 1200, 2 = 2400, 3 = 4800,
4 = 9600, 5 = 19200)
Port Configuration (must be set to 1for printer
output only)
Stop Bits (0 = one stop bit, 1 = two stop bits)
Parity (0 = none, 1 = even, 2 = odd)
Handshake Control (0 = hardware, 1 = software)
Word Length (0 = seven bits, 1 = eight bits)
Device Address (a value from 0-99)
Echo (0 = off, 1 = on)
Total Words/Bytes
LSB
MSB
LSB
MSB
bit 0
bit 1
bit 2
bit 3
bit 4
bit 5
bit 6
bit 7
LSB
MSB
LSB
MSB
LSB
MSB
LSB
MSB
1
1
1
1
1
1
6
0
1
2
3
4
5
1
1
1
1
1
1
1
1
1
1
1
1
12
0
1
2
3
4
5
6
7
8
9
10
11
.
Block Read Data Number 34: Operator Selectable Read Summary Data
Byte Definitions Byte Pos. #
Words
Start Word # Bytes Start Byte
Block Read Number 34 (Hex 22)
User Defined (Refer to Write Block #84)
1 0
