24
NVMS-1000 User Manual
Right button functions:
Menu Description Menu Description
Snap Snap picture
Open Manual
Recording
Start manual record
Start talk Start or stop talk
Camera
Configuration
Enter the interface of the area and
Camera configuration
Stream Choose stream to view. PTZ Control To display the control panel of PTZ
Enable
Audio
Enable or close audio Close Preview Close single channel preview
Full Screen To display in full screen
5.1 Preview
5.1.1 Monitory Point Preview
To start the live preview, drag the cameras from the list to
the right display window or select a window and
double-click the camera to display the live image.
You can drag the image to any window at random.
Note : Node unfold rule: After the first time for setting the
device and area, you shall obey the following rule to view
all tree nodes: when the tree node is more than 64 nodes,
the system will unfold the upper node by default.
For example: A (There is camera group AC under A; sub-area a under AC; camera group ac under
sub-area a). If the nodes number is more than 64, A will be unfolded and AC will be displayed, but a will not be
unfolded and ac will not be displayed. If the node number of A is less than 64, A will be folded and all nodes need
to be unfolded manually.
5.1.2 Stop Preview
 Close Preview of Channel
Place your mouse on the window to display the menu
toolbar, then click icon to close preview of this
channel.
 Close Preview by Right-clicking
Choose “Close Preview” by right-clicking the display
window to close preview of this channel.
 Close All Preview
Click icon on the main menu toolbar to close all
the windows.
