NVMS-1000 User Manual
The definitions of the buttons are below:
Buttons
Description
means the dome rotate up；
means the dome rotate up left;
means the
dome rotate up right;
means the dome rotate down.
means the dome
rotate left down;
means the dome rotate right down;
means the dome
rotate left;
means the dome rotate right；
means the dome stop
rotating
Drag the slider bar to adjust rotation speed of the dome
Focus button. Click
button to obtain long focus. Click
button to
obtain short focus
Iris button. Click
button to increase light of the dome. Click
button
to decrease light of the dome
Zoom button. Click
button to zoom in the picture of this camera.
click
button to zoom out the picture of this camera
Track
Auto Scan
Wiper button
Light button
Return to Area and Camera Management interface, and
then click “Cruise Line Configuration” PTZ Settings.
You can add/change/preview/delete curies.
In the Area and Camera Management interface, click ―PTZ Track Settings‖ to see the
picture on the right hand. You can set the PTZ track.
Remove camera
In the Area and Camera Management interface, select a camera, click
button to pop up a dialog
window, click
【OK】button to remove the camera.
