Appendix d - spindle and model codes – Brookfield DV-I Prime User Manual
Page 53
Brookfield Engineering Laboratories, Inc.
Page 53
Manual No. M/07-022-D0613
Appendix D - Spindle and Model Codes
Each spindle has a two-digit code, which is scrolled to via the keypad on the DV-I PRIME. The
spindle code directs the DV-I PRIME to calculate viscosity for the spindle that is being used. The
spindle multiplier constant (SMC) is used to calculate Full Scale Viscosity Range for any spindle/speed
combination (refer to Appendix E). Spindle codes are listed in Table D-1.
SPINDLE
ENTRY
CODE
SMC
SRC
RV1
01
1
0
RV2
02
4
0
RV3
03
10
0
RV4
04
20
0
RV5
05
40
0
RV6
06
100
0
RV7
07
400
0
HA1
01
1
0
HA2
02
4
0
HA3
03
10
0
HA4
04
20
0
HA5
05
40
0
HA6
06
100
0
HA7
07
400
0
HB1
01
1
0
HB2
02
4
0
HB3
03
10
0
HB4
04
20
0
HB5
05
40
0
HB6
06
100
0
HB7
07
400
0
LV1
61
6.4
0
LV2
62
32
0
LV3
63
128
0
LV4 or 4B2
64
640
0
LV5
65
1280
0
LV-2C
66
32
0.212
LV-3C
67
128
0.210
SA-70
70
105
0.677
T-A
91
20
0
T-B
92
40
0
T-C
93
100
0
Table D-1
SPINDLE
ENTRY
CODE
SMC
SRC
T-D
94
200
0
T-E
95
500
0
T-F
96
1000
0
ULA
00
0.64
1.223
DIN-81
81
3.7
1.29
DIN-82
82
3.75
1.29
DIN-83
83
12.09
1.29
DIN-85
85
1.22
1.29
DIN-86
86
3.65
1.29
DIN-87
87
12.13
1.29
SC4-14
14
125
0.4
SC4-15
15
50
0.48
SC4-16
16
128
0.29
SC4-18
18
3.2
1.32
SC4-21
21
5
0.93
SC4-25
25
512
0.22
SC4-27
27
25
0.34
SC4-28
28
50
0.28
SC4-29
29
100
0.25
SC4-31
31
32
0.34
SC4-34
34
64
0.28
CPE-40
40
0.327
7.5
CPE-41
41
1.228
2
CEP-42
42
0.64
3.8
CPE-51
51
5.178
3.84
CPE-52
52
9.922
2
V-71
71
2.62
0
V-72
72
11.1
0
V-73
73
53.5
0
V-74
74
543
0
V-75
75
213
0
