Specifications
Power supply;
Power consumption:
Amps:
LCD panel:
Panel size (diagonal):
Aspect ratio:
Micro lens array:
PT-L711XU:
PT-L701XU/PT-L511XU/PT-L501 XU:
Display method:
Drive method:
Pixels:
PT-L711XU/PT-L701 XU:
PT-L511XU/PT-L501XU:
Lens:
Lamp:
Luminosity;
PT-L711 XU
PT-L701XU
PT-L511 XU
PT-L501XU
100 V-240 V 50 Hz/60 Hz
240 W (During standby (when fan is
stopped): Approx. 5 W-10 W)
2.8 A-1.0 A
0.9 type (22.86 mm)
4:3 (16:9 compatible)
Available
Not available
3 transparent LCD panels (RGB)
Active matrix method
786 432 (1024 x 768) x 3 panels
480 000 (800 X 600) x 3 panels
Manual zoom (1 - 1 . 3 ) / focus lens
F 1.8 - 2.1, f 28.7 mm - 36.0 mm
UHM lamp (165 W)
1600 Im/ANSl
1200 Im/ANSI
1500 Im/ANSI
1200 Im/ANSI
Scanning frequency(for RGB signals):
PT-L711XU
PT-L701XU
PT-L511XU
PT-L501XU
Horizontal scanning
frequency
24 kHz - 97 kHz 24 kHz - 81 kHz
Vertical scanning
frequency
50 Hz - 120 Hz 50 Hz - 120 Hz
Dot clock frequency 135 MHz or less 110 MHz or less
YP b P r signals:
Color system:
Projection size:
Throw distance:
Optical axis shift:
Screen aspect ratio:
Installation:
Speakers:
Max. useable volume output:
NTSC (480i), 480p, PAL (625i), 720p,
HDTV (1080i/1035i)
6 (NTSC/NTSC 4.43/PAUPAL-M/PAL-
N/SECAM)
762 mm - 7620 mm (30" - 300")
1.1 m -11.7 m (3'8"- 38'4")
9:1 (fixed)
4:3
Front/Rear/Ceiling/Desk (Menu selection
method)
2.8 cm round x 2
2 W (1 W + 1 W) (stereo)
48
