Specifications

Input Signal Preset Data

Optional Accessories

Dimensions

VPL-PX40

Projection system

3 LCD panels, 1 lens projection system

LCD panel

Projection lens

0.99-inchp-Si TFT Sony LCD panel with Micro Lens Array

2,359,296 pixels (786,432 pixels x 3)

Approx. 1.3 times zoom lens, F1.7 to 2.3, f37.6 to 48.8 mm

Lamp

265 W UHP Lamp

Screen coverage

40 to 300 inches (viewable area, measured diagonally)

Light output

3500 ANSI lumens*

1

Color system

BTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL-N (automatically/manually selected)

Resolution

Video: 750 TV lines, RGB: 1024 x 768 pixels

Acceptable signals

Cabinet color

RGB (fH 19 to 92 kHz, fV: 48 to 92 Hz (up to UXGA), 15 kHz RGB Component

50/60 Hz,Progressive component 50/60 Hz, DTV (480/60i,575/50i,480/60p, 540/60p,

575/50p, 720/60p,720/50p, 1080/60i, 1080/50i) Composite video, Y/C video

White

Speaker

Stereo speakers system 40 x 70 mm (1 5/8 x 2 7/8 inches) Max. 2W x 2

Power requirements

100 to 240 V, 50/60 Hz

Power consumption

Max. 365 W, Standby 6 W

Operating temperature

0 to 35˚C (32 to 95˚F)

Operating humidity

35 to 85%

Dimensions

420 (W) x 115 (H) x 316 (D) mm (16 5/8 x 4 5/8 x 12 1/2 inches)

Mass

Approx. 7.5 kg (16 lb 10 oz)

Heat dissipation

1246 BTU

Composite

VIDEO IN

INPUT A

INPUT B

INPUT C

INPUT D

USB
OUTPUT

REMOTE

CONTROL S IN/
PLUG IN POWER

Phono type, 1.0 Vp-p ±2 dB sync negative, 75 Ω

Y/C IN

Mini DIN 4-pin

Y

1.0 Vp-p ±2 dB sync negative, 75Ω

C

Burst 0.286 Vp-p ±2 dB (NTSC), 75Ω or 0.3 Vp-p ±2 dB (PAL), 75Ω

HD D-sub 15-pin (female)

Analog RGB

HD D-sub 15-pin (female)

R

0.7 Vp-p ±2 dB positive, 75Ω

G

0.7 Vp-p ±2 dB positive, 75Ω

G with Sync

1.0 Vp-p ± 2dB sync negative, 75Ω

B

0.7 Vp-p ± 2dB positive, 75Ω

SYNC/HD
Composite sync

1.0 to 5.0 Vp-p, high impedance positive/negative

Horizontal sync

1.0 to 5.0 Vp-p, high impedance positive/negative

VD
Vertical sync

1.0 to 5.0 Vp-p, high impedance positive/negative

AUDIO IN

Stereo mini jack, 500 mV rms, impedance more than 47 kΩ

Analog RGB

HD D-sub 15-pin (female)

R

0.7 Vp-p ±2 dB positive, 75Ω

G

0.7 Vp-p ±2 dB positive, 75Ω

G with Sync

1.0 Vp-p ± 2dB sync negative, 75Ω

B

0.7 Vp-p ±2 dB positive, 75Ω

SYNC/HD
Composite sync

1.0 to 5.0 Vp-p, high impedance positive/negative

Horizontal sync

1.0 to 5.0 Vp-p, high impedance positive/negative

VD
Vertical sync

1.0 to 5.0 Vp-p, high impedance positive/negative

AUDIO IN

Stereo mini jack, 500 mV rms, impedance more than 47 kΩ (Shared by INPUT B/C)

AUDIO IN

Stereo mini jack, 500 mV rms, impedance more than 47 kΩ (Shared by INPUT B/C)

Digital RGB

DVI-D (TMDS)

Analog RGB/Component
R/R-Y

0.7 Vp-p ±2 dB positive, 75Ω

G

0.7 Vp-p ±2 dB positive, 75Ω

5 BNC (Female)

G with Sync/Y

1.0 Vp-p ±2 dB sync negative, 75 Ω

B/B-Y

0.7 Vp-p ±2 dB positive, 75Ω

SYNC/HD
Composite sync

1.0 to 5.0 Vp-p, high impedance positive/negative

Horizontal sync

1.0 to 5.0 Vp-p, high impedance positive/negative

VD
Vertical sync

1.0 to 5.0 Vp-p, high impedance positive/negative

AUDIO IN

Stereo mini jack, 500 mV rms, impedance more than 47 kΩ

Up (female) x 1 (Shared by INPUT A/B/C/D)

MONITOR OUT*

2

HD D-sub 15-pin (female) R/R-Y, G/Y, B/B-Y: Gain Unity, 75Ω SYNC/HD, VD: 4.0 Vp-p (open), 1.0 Vp-p (75 Ω)

RS-232C

D-sub 9-pin (female)

AUDIO OUT (Variable out)

Stereo mini jack, max. 1 V rms, when the input siginal is 500 mV rms, impedance less than 5 kΩ

ETHERNET port

RJ-45: 10 BASE-T/100 BASE-TX

Stereo mini jack

5.0 Vp-p, plug in power, DC 5V

UL, cUL, DHHS, FCC Class A, IC Class A, NEMKO, CE (LVD), CE (EMC), C-Tick, CCC, VCCI class B, JEITA

Laser type

Class II

Wavelength
Output
Remote commander, Monitor Cable (2 m): HD D-sub 15-pin to HD D-sub 15-pin, USB Cable A type to B type (2 m),
AA size Battery (x 2), Lens Cap, Air Filter, Operating Manual, Installation Manual for dealers

645 nm

1 mW

Model
Optica

Signals

General

Inputs/Outputs

Safety regulations
Laser beam

Supplied
accessories

No.

1
2
3
4
5
6*
7*
8*
9*

10*
11*
12*
13*
14*
15*
16*
17*
18*
19*
20*
21*
22*
23*
24*
25*
26*
27*
28
29
30*
31
32*
33
34*
35
36*
37
38
39
43
44
45
47
48
50
52

Preset Signal

VIDEO/60 60Hz

15.734 59.940
15.625 50.000
15.734 59.940 SonG/Y
15.625 50.000 or
33.750 60.000 Composite
31.469 70.086 P/N
37.861 85.080 P/N
24.823 56.416 N/N
31.469 70.086 N/P
37.861 85.080 N/P
31.469 59.940 N/N
35.000 66.667 N/N
37.861 72.809 N/N
37.500 75.000 N/N
43.269 85.008 N/N
35.156 56.250 P/P
37.879 60.317 P/P
48.077 72.188 P/P
46.875 75.000 P/P
53.674 85.061 P/P
49.724 74.550 N/N
35.524 86.958 P/P
48.363 60.004 N/N
56.476 69.955 N/N
60.023 75.029 P/P
68.677 84.997 P/P
63.995 70.019 P/P
67.500 75.000 P/P
77.487 85.057 P/P
61.795 65.960 N/N
71.713 76.047 Cneg(N/P)
60.000 60.000 P/P
75.000 75.000 P/P
46.433 86.872 P/P
53.316 50.062 SonG(P/P)
63.974 60.013 P/P
79.976 75.025 P/P
91.146 85.024 P/P
75.000 60.000 P/P
31.470 60.000 SonG
31.250 50.000 SonG
28.130 50.000
45.000 60.000
37.500 50.000
33.750 60.000
63.981 60.020 N/N

VIDEO/50 50Hz
480/60i
575/50i
HDTV 1035/60i, 1080/60i
640x350

640x400

640x480

800x600

832x624
1024x768

1152x864

1152x900

1280x960

1280x1024

1600x1200

VGA-1(VGA350)
VESA 85(VGA350)
NEC PC98
VGA-2(TEXT)/VESA70
VESA 85(VGA400)
VESA 60
Mac 13
VESA 72
VESA 75(IBM M3)
VESA 85(IBM M4)
VESA 56
VESA 60
VESA 72
VESA 75(IBM M5)
VESA 85
Mac 16
VESA 43(8514)
VESA 60
VESA 70
VESA 75
VESA 85
VESA 70
VESA 75
VESA 85
SUN LO
SUN HI
VESA 60
VESA 75
VESA 43
SGI-5
VESA 60
SXGA VESA75
SXGA VESA85
UXGA VESA60

480/60p (double frequency of NTSC)
575/50p (double frequency of PAL)
1080/50i
720/60p
720/50p
540/60p
1400x1050 SXGA+

fH

(kHz)

fV

(Hz)

H/V

When the signal other than ones in "Preset Signals" are input,
the picture may not display correctly. When the aspect ratio of
an input signal is other than 4:3, a part of the screen is
displayed in black. The UXGA signal can be projected only
when user set the frequency of a computer 60Hz. The digital
input complies with the signals marked with asterisks(*) on the
table. When the digital signal output from a computer is a
signal other than the signals marked with asterisks(*) among
the memory numbers 6 to 39, it is automatically output
according to the specifications of the projector. The memory
numbers 22 and 34 are the interlace signals.

Signal Cables

SMF-400

(HD D-sub 15-pin to 5 BNC, for
RGB signal)

SMF-410

(HD D-sub 15-pin to HD D-sub
15-pin, for RGB signal)

Optional Lenses

VPLL-FM22

(Fixed short-focus lens)

VPLL-ZM102

(Long-focus zoom lens)

*

1

ANSI lumens is a measuring method of the American National Standards Instisute IT7. 228. Since there is no uniform method of measuring

brightness, specifications will vary among manufactures. *

2

DIGITAL RGB and Component signals are not output from the MONITOR OUT

terminal. *

3

Not available in some areas. For details, please contact your nearest Sony office.

©2002 Sony Corporation. All rights reserved.

Reproduction in whole or in part without permission is prohibited.

Features and specifications are subject to change without notice.

All non-metric weights and measures are approximate.

Sony is a registered trademark of Sony Corporation.

Mac is registered trademark of Apple Computer, Inc.

Printed in Japan on recycled paper.

MK07852V1FRT02NOV

Distributed by

420(16 5/8)

145(5 3/4)

87(3 1/2)

316(12 1/2)

115(4 5/8)

Power consumption during standby 6.0W or less.
Halogenated flame retardant is not used in cabinets.
Lead-free solder is used for soldering.
Polystyrene form for cushioning has been eliminated
and corrugated paper is used as buffer materials.

Unit:mm (inches)
