VCR and Cassette Information
Erase Protection (Record Tab)
Cassettes have a record tab to ensure that
recordings are not accidentally erased.
To prevent accidental
erasure, break off the tab
with a screwdriver.
To record again, cover the
hole with cellophane tape.
Maximum Record/Piayback Time
Only use tapes with the iVHSImark in this unit.
Tape Speed
Position
Type of Video Cassette
T60 T120 T160
SP
(Standard Play)
1 Hour 2 Hours
2 Hours
40 Minutes
LP
(Long Play)
2 Hours 4 Hours
5 Hours
20 Minutes
SLP
(Super Long Play)
3 Hours 6 Hours 8 Hours
Reset all VCR Memory Functions
This operation is convenient when moving the VCR to a new
location, or if a mistake was made in the One Time VCR
Setup section. Make sure a tape is not inserted in the VCR.
1) Turn VCR Power on.
2) Press and hold both Play and Rewind buttons on the
VCR for more than 5 seconds.
• The power will shut off.
3) Perform the One Time VCR Setup section on page 10.
D.S.T. (Dayiight Saving Time)
Spring:
First Sunday in April (DAYLIGHT SAVING TlME:AUTO)
Automatically adds one hour and adjusts the clock.
NORMAL TIME
1:00 a.m. 2:00 a.m.
DAYLIGHT
SAVING TIME 3:00 a.m. 4:00 a.m.
Autumn:
Last Sunday in October (DAYLIGHT SAVING TIME:
AUTO) Automatically turns back one hour and adjusts
the clock.
DAYLIGHT
SAVING TIME
1:00 a.m. 2:00 a.m.
NORMAL TIME
1:00 a.m. 2:00 a.m.
i Cieaning Care for Video Heads
or
Clogged Video
Head Picture
Blue Back
(During playback of
pre-recorded tape)
Blue Back
Screen
Clogged Video Heads
While your VCR will not normally require head cleaning,
however the heads may become clogged when playing
an old or damaged tape. If the image on your screen
resembles the illustration on the left or the screen
becomes solid blue when playing back a pre-recorded
signal on the tape, the heads probably require cleaning.
Cleaning the Heads
It is recommended that head cleaning be performed by
a qualified service technician. Please contact your
nearest Panasonic Service Center. An alternate
solution is to obtain a head cleaning cassette. Be sure
to follow the cleaning instructions carefully. Excessive
use of a cleaning cassette could shorten head life.
Use this cassette only when symptoms occur.
Product Specifications
Power Source:
Power Consumption:
Video Signai:
Video Recording System:
Audio Track:
Tuner:
Broadcast Channeis:
CATV Channeis:
120V AC, 60 Hz
Approx. 23 watts (Power on)
Approx. 7 watts (Power off)
EIA Standard NTSC color
4 rota^ heads helical
scanning system
1 track (Normal)
2channel (Hi-Fi Audio Sound)
VHF 2~13, UHF 14-69
Midband A through I (14-22)
Superband J through W
(23-36)
Hyperband AA-EEE (37-64)
Lowband A-5-A-1 (95-99)
Special CATV channel 5A (01)
Ultraband 65-94,100-125
4rF-104®F (5X-40®C)
10%-75%
8.4 lbs. (3.8 Kg)
14-315/16” ( W ) X 3-1/2" ( H ) X
11-1/4" (D)
380 (W) X 89 (H) X 285 (D) mm
Note: Designs and specifications are subject to change
without notice.
Operating Temperature
Operating Humidity
Weight:
Dimensions:
