VCR Plus+ programming allows you to set most items of a timer recording by simply entering a special code found in TV GUIDE

magazine as weii as the TV listings in selected newspapers. In order for the VCR to read this special code, some set up is required.

A Guide (VCR Plus+) channel number is assigned to each local broadcast and cable station. Because this number sometimes
differs from the channei your TV receives the station on, it is necessary to program the VCR with local channel information.

REW«

FF«

гЕпти« aiM **£1!**=

О © ® ©

Qçbû Q

Channel Set Up Preparations

NOTE: Complete the steps on this page If your

VCR hook-up resembles “B” on page 24.

Prepare a list like the example below.

This list will help you smoothly enter the information

needed in step 4 at right.

You will need the following to complete the list:
■ A line up of normal and/or cable stations you

receive along with the channel numbers your TV
receives them on. A cable channel line-up chart
is supplied by your cable company.

H A list of Guide (VCR Plus+) channel numbers

assigned to the stations you receive. This list is
available in TV Guide and the TV listings found

in selected newspapers.

1 Make a chart with 3 columns like the example

below. In the left column, fill in the name or call

letters of the stations you receive.

O In the middle column, fill in each station's

assigned Guide (VCR Plus+) number found in
TV Guide, newspapers, etc.

O In the right column, fill in the channel number

that your TV receives the station on from your
channel line-up.

EXAMPLE ONLY

Broadcast or Cable

Station Name

Assigned

Guide

(VCR PIUS+)

channel no.

Channel no.

your TV

receives the

station on

HBO

Nickelodeon

CBS

FOX

VCR Plus+ Channel Set Up

(For connection B on page 24 only)

MENU

Push MENU

to display the

menu.

Rotate and push

the WHEEL to

select SET UP

CHANNEL.

......................... MENU .............................

SET UP VCR
SET CLOCK

SET UP CHANNEL

Ш1М1А/ LANGUE: ENGLISH

SELECT
SET
END

ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY

Rotate and push

the WHEEL to

select VCR Plus-i-

CH SET UP.

--- SET UP CHANNEL ---

ANTENNA SYSTEM : CATV
AUTO SET

SELECT

SET
END

ROTATE WHEEL

PUSH WHEEL

PUSH MENU KEY

IMPORTANT NOTE;

For this step, use the list you prepared. You may leave lines

blank if, you don’t receive that station, or the GUIDE CH

number and the CATV (or TV) CH numbers are the same.

Push WHEEL to

move the

shaded area on

the right side.

VCR PKÜ+ CH SET UP

GUIDE CH CATV CH

•*

БО

SELECT ;

ROTATE WHEEL

SET :

PUSH WHEEL

END

PUSH MENU KEY

ъ___________

Then, rotate the Wheel

to change CATV or TV CH number.

Next, push the Wheel

to enter CATV or TV CH number.

Now, rotate the Wheel

to continue.

Repeat this operation until the list is complete.

To Make Corrections

Rotate and push the Wheel to select the incorrect CATV or TV
CH number. Then, Push CLEAR to delete the numbers.
Now, use the Wheel to re-enter the channel.

Push MENU

twice

exit the VCR Plus-i-

CH SET UP mode.

MENU

Make your entries within 60 seconds or the VCR will
leave №is mode.

Once local channels have been programmed, they will
stay in memory, even in the case of a power failure.
