MTS Broadcast/ VHS Hi-Fi Stereo System

i^c

Check list before you begin.

□ The D-VHS VCR is connected to a stereo or Digital TV, or a mono TV and an external stereo amp or receiver with speakers.

D The D-VHS VCR and other components are plugged in and turned on.

Connections

to Make

To monitor recording in progress in
stereo, connect D-VHS VCR to stereo

TV or mono TV and stereo amp with

speakers.

Receivable Broadcast Types

The following are possible audio broadcast types and on-screen displays.

The signal(s) not being received is enclosed in parenthesis. The currently
selected audio mode is indicated with an arrow.

Press DISPLAY

to display the broadcast signal

currently being received.

MTS Stereo and SAP broadcast

Multi-channel Television Sound Stereo
(main language) and Secondary Audio
Program (sub language) broadcasts are
being received simultaneously. Select
STEREO or SAP audio mode.

MTS Stereo broadcast

Multi-channel Television Sound Stereo

broadcast. Select STEREO audio mode.

• , If a stereo broadcast is weak and the display

flickers, you may want to select the MONO
audio mode for better results.

SAP broadcast

Secondary Audio Program (sub language)
broadcast. Select SAP audio mode for the
sub language.

MONO broadcast

Normal monaural sound broadcast.

AM CHOa

0:00:00

STEREO ■*
SAP

MONO

12;00AM CHOe

0:00:00

STEREO ■*

(SAP)

MONO

AM CHOB

0;00-.00

(STEREO)

SAP i

MONO

12:00AM CHOe

0:00:00

(STEREO)
(SAP)

MONO
