A
udio
Muiti-piex
broadcast system
The enjoyment oi Audio Multi-Plex Broadcasting is yours, even when you are watching a mono sound TV, by
using stereo AMP and speakers or a Headphones. You may select the type o1 broadcast and sound track you
wish to record with a single switch.
CONNECTIONS
AUDIO n
INDICATOR
STEREO
INDICATOR
MONO
INDICATOR
REC LEVEL
FRONT METER
mono Mereo speaker
speaker TV TV
STEREO AMP
monitor TV or RECEIVER
1 OR OR
.
m
--- 7
0
t—------
-
AUDIO OUT
SELECT BUTTON INPUT AUDIO
SELECTOR SWITCH
\
HEADPHONES
JACK
VIDEO OUT
\
AUDIO OUT (UR)
PROGRAM INDICATORS
The various combinations ot Program Indicators described below will light when broadcast signals are received.
The type of broadcasts possible are arranged down the left side of the chart on the next page.
MONO
I---- fV STEREO------1
ISTEIpEO AUDIO n I
a
MAIN
-SAPI
~SAP2
Press
When a program in stereo is received, the STEREO Indicator
lights up.
When a second audio program is received, the AUDIO H
Indicator lights up.
-• When a stereo and second audio program is received, both
STEREO and AUDIO ^ Indicators light up.
— ' Lights up when the MONO Button is set to MONO. When no
indicators are lit a mono broadcast is being received.
RECORDING OF AUDIO II OR STEREO A AUDIO fl BROADCASTS
STEREO, AUDIO D or STEREO & AUDIO II Broadcasts are recorded on the cassette in
Hi-Fi and NORMAL sound simultaneously, when the STEREO or AUDIO D Indicator is on.
Use the recording operations in “TO RECORD A TV PROGRAM" on page 11 with the
addition of the desired recording settings as shown on the next page.
USING THE MONO BUTTON
If there is noise and the STEREO or AUDIO D indication is intermittent it may be desirable
to set the MONO Button to the MONO position to improve sound quality.
MONO Indicator lights up on the front Panel. You may set this MONO position with
CHANNEL MEMORY (see page 32).
NOTE:
• This will also function during Timer Recording or One Touch Recording.
• Set this button to desired position before Timer Recording.
- 2 7 -
