Finding the Controis / Setup

Overview

Recording paper

entrance

Paper tray

Document feeder tray

Cover open button

Note:

• The document and recording paper will be ejected from the front of the unit, install the unit on a desk or

floor with a smooth surface and do not place anything in front of the unit.

Before installation

Remove the shipping tape.

Open the cover by pressing the cover open button.

Lift the film cartridge, remove the leaflet and

replace the film cartridge.

Close the cover securely by pushing down on the
dotted area at both ends.

Film

cartridge

^ Cover open

button

Dotted area

Leaflet
