CONTROLS AND FUNCTIONS

® VOLUiWE

Controls the output level of all audio channels.

This does tiot affect the OUT (REC) level.

(D n PHONES (SILENT CINEMA)

Allows you to enjoy DSP effects when listening with

headphones.

© SPEAKERS A/B/OFF

Selects the set of front speakers connected to the A or B

terminals. To turn off the speakers, press the button
repeatedly and select OFF.

© STEREO (EFFECT)

Switches between normal stereo and DSP effect

reproduction. When you select STEREO, the unit mixes
down all Dolby Digital ;md DTS signals (except the LEE
channel) as well as those 2-channel signals without effect

sounds to the front left and right speakers.

® TONE CONTROL

Sw'itches between Bass (low-frequency response) control

mode and Treble (high-frequency response) control mode.

© PROGRAM O/O

Use to select sound field programs.

© BASS/TREBLE-/+

Increase or decrease low/high-frequency response when

the unit is in Bass/Treble control mode. The sound
changes 2dB each time you press one of these buttons.
Control range; -10 to -l-lOdB.

Sets the priority for the types of input signals (AUTO,

DTS, ANALOG) received wdien one component is
connected to tw'o types of input jacks. You cannot set
priority for an audio sources if you have selected 6CH

INPUT as the input source.

Selects the input source you w'ant to listen to or watch.

Selects the audio source connected to the 6CH INPUT

jacks. This selection takes priority over sources selected

with INPUT (or the input selector buttons on the remote

control).
