2. RS422
The optional Editing Controller AG-A0OO can be used
with the WJ-MX50 to control it remotely in the VTR
Editing System.
2, Refer to the table below for transmitting protocol
between the RS232C DT/WJ-MX50 connection.
3.
SW701
Setting up
No. Switch Name Description
• Turn the J^S422/RS232C Selection Switch (133) 1. Bit length ON - 8 bits
on the rear panel to the RS422 position. OFF - 7 bits
• Connect the control cable between the AG-A800
and the Editing Controller Connector (132) on the
2. Stop bit ON - 2 bits
WJ-MX50.
OFF - 1 bit
• The pin configuration of the Editing Controller
3. Parity ON - OFF, OFF-ON
Connector (132) is as follows.
1. Ground 4. Even/Odd ON (Odd) Of OFF (Even)
2. Transmit A
5.
_
OFF
4. Receive Common 6, 7, 8 BAUD rate No. 6 No. 7 No. 8
5. Spare OFF OFF OFF — > 19.2 kbps
6. Transmit Common ON OFF OFF — r 9.6 kbps
7. Transmit B OFF ON OFF —> 4.8 kbps
8. Receive A ON ON OFF —> 2.4 kbps
9. Ground' OFF OFF ON —> Inhibited
ON OFF ON ^ Inhibited
OFF ON ON —> Inhibited
RS232C ON ON ON —> Inhibited
can be used with the WJ-MX50 for remote operation.
Setting up the switch
• Open the top panel by removing the 14 case
screws.
• Set the switch {SW701) referring to the Note-2
and 3 below.
• Close the top panel by fixing 14 case screws after
setting the switch correctly.
Notes :
1. Make the required conversion cable referring to
the following wiring information.
SW702
No. Switch Name Description
1. RS422 Parity ON - Odd
OFF - Even (Factory Setup)
2 - 8 - Ail OFF
3. The switch (SW701) has been set as follows at
factory. Change this basic setting up to meet
necessary Modem requirements.
SW701
ON OFF
RS232C WJ-■MX50
25-pin 9-piri
2 TXD 3 TXD
3 RXD 2 . RXD
4 RTS 7 RTS
5 CTS 8 CTS
6 DSR 6 DSR
7 SIG. G 5 SIG. G
20 DTR 4 DTR
[~TTTT 1
r~rTTT 1
rnrrn
r~nm
nm I
nnsn
BAUD RATE
SW-8
SW-7
SW-5
SW-5
SW-4
SW-3
SW-2 ] STOP BIT
SW-1 ] BIT LENGTH
SW702
ON OFF
[DCE Connection]
czu
d[
cin
sw-e
SW-7
SW-6
SW-5
SW-4
SW-3
SW-2
SW-1 RS422 Parity
- 39 -
[Factory Setup Mode]
