Recommended setting of “Digital Audio Out­
put”
Make settings as shown in table below depending on the kind
of equipment that is connected to the optical/coaxial digital au­
dio output connector.
Type of equipment
connected
Recommended setting
1 LPCM
96k-^48k
2 Dolby
Digital
3 dts
No equipment is
connected
No Bitstream PCM
AV amplifier (with
digital audio input
connector) without
Dolby Digital/dts
decoder
Yes*2 PCM*1 PCM*'
Dolby Digital
(AC-3) decoder
(See page 12.)
Yes*^ Bitstream PCM
Dolby Digital
(AC-3)/dts decoder
(See page 12.)
Yes*2 Bitstream Bitstream
•Underlined items are factory preset.
When connecting an amplifier (with an optical/coaxial digital
input connector) which does not contain a Dolby Digital
(AC-3) or dts decoder, be sure to select “PCM" at the
“2 Dolby Digital” and at the “3 dts". If “Bitstream" is selected,
any attempt to play DVDs (or CDs recorded in dts) may
cause such a high level of noise that it may be harmful to
your ears and damage your speakers.
*2 96 kHz LPCM sound is converted to 48 kHz 16 bit sound
when this player is connected with an optical digital audio
cable or coaxial audio cable.
Do the following if you wish to take advantage of high quality
96 kHz sound.
Select ‘‘1 No” and connect this player’s audio output connec­
tor to an amplifier’s audio input connector with the audio/
video cable (included) or an audio cable (not included).
Note that LPCM, Dolby Digital and dts signals will all be out­
put in 2 channel, analog form.
Speaker setting
1 At the initial settings screen (on page 30)
Tilt the joystick (A, ▼) to select “8 Speaker
Setting” and press SELECT.
Center
Large/Small/No
Front (L)
Large/Small
Center
Delay time'
(0_ms)
Exit
Test
signal
Sf eakerSettin
--
«SL r
“"1
Exit
■ire™
Center
Channel balance (0_dB)
X'
---------
dB
i|ii|i[aL
ress 3ETUftMto :ancèl
Surround (L)—
Large/Small/No
-Front (R)
Large/Small
— Subwoofer
Yes/No
Subwoofer
Channel
balance (Q_dB)
Surround (R)
Large/Small/No
Surround (R)
Channel balance (0_dB) Surround (L)
Channel balance
(Q_dB)
Surround (L/R)
Delay time*
fO ms)
»Underlined items are factory preset.
'Delay time adjustment is effective only for DVDs recor­
ded in Dolby Digital (AC-3).
2
Tilt the joystick (A, T, ◄,
item and press SELECT.
►) to select the
Tilt the joystick (A, ▼) to select the setting
and press SELECT.
Speaker icons:
• If the speaker is connected, display the icon with the joy­
stick ( A , ▼) and press SELECT.
• If the speaker supports low-frequency (under 100 Hz)
reproduction, select the large icon. If the speaker does
not support low-frequency reproduction, select the small
icon. [When a subwoofer is not connected, be sure to
select “Large” for the front speakers (UR).]
In case of surround speaker (L)
No Large/Yes Small/Yes
(Continued on the next page)
