Figure 7-50
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type
The abnormal events include: no disk, no space, disk error, net error.
You need to draw a circle to enable this function.
Normal
Out
The corresponding alarm activation output channel when alarm occurs,
There are three channels.
Latch
The alarm output can delay for the specified time after alarm stops.
Then system disables alarm and corresponding activation output.
The value ranges from 10s to 300s.
Send
email
If you enable this function, system can send out email to alarm the
specified user.
Alarm
upload
System can upload the alarm signal to the network (includes the alarm
centre.)
Show
message
System can display alarm information in local DVR screen.
7.3.4 Additional Function
7.3.4.1 ATM/POS
The ATM/POS function is the same with the card overlay function (chapter 5.5.8). It is mainly for
financial areas to Sniffer, information parse and character overlay. The ATM/POS interface is
shown as in Figure 7-51.
