9145E NID Software User’s Manual

Port Information

Port Configuration

3. Drop Packets with VLAN Tag not matching VLAN Tag A? The 9145E discards all Service

frames received on the User or Network port that do not have a VLAN Tag matching VLAN Tag A.

Selecting Yes discards packets.

4. Remove outermost VLAN Tag? Removes the outermost VLAN Tag from packets received on the

User or Network port. Takes no action on untagged packets. Yes removes outermost tag.

5. Add VLAN Tag B to Untagged Packets only? Yes adds VLAN Tag B to all untagged packets

received on the User or Network port.

6. Add VLAN tag C to tagged packets only? Yes adds VLAN Tag C to all tagged packets received

on the User or Network port.

7. Add VLAN Tag C to Tagged Packets only using P-Bits of outermost VLAN tag? Yes adds

VLAN Tag C to all tagged packets received on the User or Network port, using the same priority bit

as the inner tag of the packets.

8. Tag A VLAN ID (0-4094) Sets VLAN ID for Tag A. The ID range 0 - 4094 is valid.
9. Tag B VLAN ID (0-4094) Sets VLAN ID for Tag B. The ID range 0 - 4094 is valid.

Priority (0 - 7)

Sets P-Bit of VLAN Tag B. Values of 0-7 are Valid.

10. Tag C VLAN ID (0-4094) Sets VLAN ID for Tag C. ID setting of 0 - 4094 are valid.

Priority (0 - 7)

Sets P-Bit of VLAN Tag C. Values of 0-7 are Valid.

Figure 5-7 Ingress VLAN Rules screen

Canoga Perkins Corp. Ethernet Network Interface Device 29-JAN-2009
9145E-101-1-0 V03.10(GA0014) 10:19:54
----------------------------------INGRESS VLAN RULES---------------------------

Ports: User Net
1) Port Interface Type S-TAG C-TAG
2) Drop Untagged Packets? No No
3) Drop Packets with VLAN Tag
not matching VLAN Tag A? No No
4) Remove outermost VLAN Tag? No No
5) Add VLAN Tag B to Untagged Packets only? No No
6) Add VLAN Tag C to Tagged Packets only? No No
7) Add VLAN Tag C to Tagged
Packets only using P-Bits
of outermost VLAN tag? No No
8) Tag A VLAN ID (0 - 4094) 0 0
9) Tag B VLAN ID (0 - 4094) 0 0
Priority (0 - 7) 0 0
10) Tag C VLAN ID (0 - 4094) 0 0
Priority (0 - 7) 0 0

Select [1-10]:
------------------------------------Messages-----------------------------------
