Diagnostics
PING Generation
44
4. To enter the Ping VLAN ID, type 4 and press Enter. The VLAN ID is only writable if the Ping from
Address is the Test IP, or the Aux IP if Aux Allow Any VLAN is enabled.
5. To enter the Ping Payload Size, type 5 and press Enter. Type a value between 40 and 9950. To
send packets greater than 1518 (payload size greater than 1472), the DF (Don't Fragment) bit
must be set or the packet will be fragmented (sent as multiple packets of size 1518).
6. To change the Ping DF Bit setting, type 6 and press Enter. See the Ping Payload size for
explanation.
7. When you are finished entering values, type 7 to start pinging and press Enter. The PING test
starts (Figure 4-5).
8. When the test is complete, press Esc to return to the PING Generation screen.
Figure 4-4 PING Generation screen
Canoga Perkins Corp. Ethernet Network Interface Device 29-JAN-2009
9145E-101-1-0 V03.10(GA0014) 11:20:59
-------------------------------PING GENERATION---------------------------------
1) Ping to Address : 0.0.0.0
2) Ping from Address : Auto Selection
3) Ping Count : 0
4) Ping VLAN ID : 0
5) Ping Payload Size (40 - 9950) : 40
6) Ping DF Bit : Clear
7) Start Pinging
Select [1-7]:
------------------------------------Messages-----------------------------------
