3240S F I B E R O P T I C M U L T I P L E X E R
3240S Fiber Optic Multiplexer
Chapter 6 - Technical Specifications
6.1 Optical Interface
Composite Error Rate: 1 in 10 9 or better
Mode of Transmission: Fiber Optic Cable
Fiber Compatibility: 50 to 62.5 micron multimode fiber (850nm, 1310nm)
or 8 to 10 micron single mode fiber (1310nm, 1550nm)
Transmitter: Infrared LED or laser diode
Wavelength: 850nm, 1310nm, 1550nm
Fiber Optic Connector: ST or FC
LO/HI Optical Power Switch: Reduces 850nm Tx power by approximately 6dB
Reduces 1310nm Tx power by approximately 3dB
Receiver:
850nm LED Option PIN diode standard
1310nm Laser Option PIN (InGaAs) diode
1550nm Laser PIN (InGaAs) diode
Transmission Code: Proprietary
Loss Budgets:
Multimode Options:
*850nm LED 15dB with 62.5/125m fiber
*1310nm low power laser 13dB with 62.5/125m fiber
*1310nm high power laser 23dB with 62.5/125m fiber
Single Mode Options:
*1310nm low power laser 13dB with 8/125m fiber
*1310nm high power laser 23dB with 8/125m fiber
*1550nm high power laser 23dB with 8/125m fiber
* Loss budgets are typical. Guaranteed loss budgets are 2dB lower.
6-1
