3240S F I B E R O P T I C M U L T I P L E X E R

3240S Fiber Optic Multiplexer

4.3.3 Network Management Module Setup

The steps to set up of the SNMP Management Module (NMS) are as follows:

•

Designate and set Time Slot jumpers on interface cards.

•

Set Configuration Switches (e.g., line buildout, line coding) on interface cards, as required.

•

Set Configuration Switches on Main Board (rear panel Master/Slave, Optics HI/LO Power), as required.

•

Set all system and I/O Port loopback switches to NOR.

•

If equipped with redundant optics, set the PRI/AUTO/SEC Switch to AUTO.

•

Set the DTE/DCE Switch on the SNMP Management Module to the required setting. If the device you are connecting
to the 3240S is a modem, this switch is set to DCE. If the device being connected to the 3240S is a PC or terminal, this
switch needs to be set to DTE. Plug in your EIA-232 cable, male/male straight-thru to the NMS Module.

Details for the setup of switch and jumper selections can be found in Chapter 2.

4-4
