3240S F I B E R O P T I C M U L T I P L E X E R

3240S Fiber Optic Multiplexer

TABLE 2-A

T1 I/O Card Switch Settings

DIP Switch Position

Line Length

Application

SW1, SW3 SW1, SW3

1

2

3

4

5

6

7

8

O

O

C

*

O

O

C

*

0 – 133ft. **

***DSX-1 ABAM Wire (AT&T 600B/600C)

C

C

O

*

C

C

O

*

133 – 266ft.

***DSX-1 ABAM Wire (AT&T 600B/600C)

O

C

O

*

O

C

O

*

266 – 399ft.

***DSX-1 ABAM Wire (AT&T 600B/600C)

C

O

O

*

C

O

O

*

399 – 533ft.

***DSX-1 ABAM Wire (AT&T 600B/600C)

O

O

O

*

O

O

O

*

533 – 655ft.

***DSX-1 ABAM Wire (AT&T 600B/600C)

O

C

C

*

O

C

C

*

AT&T CB113

Repeater

C

O

C

*

C

O

C

*

FCC Part 68, Opt A

CSU Network Infc

O

O

C

*

O

O

C

*

ANSI T1.403

CSU Network Infc

C

C

C

*

C

C

C

*

RESERVED FOR E1

DO NOT USE FOR T1

(O) = Open

(C) = Closed

*

Open = Alternate Mark Inversion Coding (AMI) or Closed = Binary 8 Zero Suppression Coding (B8ZS)

SW1

SW3

W32

2-6

Figure 2-6

I/O Card Switches
