Line 2: The name of the NDB.
Lines 3-4: The latitude and longitude
of the NDB
If the NDB is being viewed as part of
the
nearest NDBs list (see section
3.8.1), the NDB 1 page format will dif-
fer as follows (see figure 3-149):
Line 1: After the NDB identifier, the number designating the NDB’s
position in the nearest NDB list is displayed. In figure 3-149, DFI is
the nearest NDB.
Lines 3-4: In place of the latitude/longitude, line 3 is blank and line 4
displays the magnetic bearing to or the magnetic radial from the NDB
and the distance in nautical miles. Placing the cursor over the
radial/bearing field and pressing
E
toggles between radial from and
bearing to station.
3.11.3.2. The NDB 2 Page
See figure 3-150.
Line 1: The NDB identifier, preceded
by an arrow if it is the active waypoint.
Line 4: The magnetic bearing to or the magnetic radial from the NDB
and the distance in nautical miles. Placing the cursor over the
radial/bearing field and pressing
E
toggles between radial from and
bearing to station.
3.11.4. SUPPLEMENTAL WAYPOINT PAGES
The Supplemental waypoint pages (SUP 0, SUP 1, SUP 2, and
SUP 3) allow you to create “custom” waypoints for use in navigation.
A crop sprayer might want to create a waypoint on a field that is
sprayed regularly, for instance. Another candidate might be a small
airport which is not included in the KLX 135A data base. To learn
how to create a user-defined waypoint, see section 4.4.
3.11.4.1. The Supplemental 0 (SUP 0) Page
See figure 3-151.
NOTE: The SUP 0 page is only dis-
played for waypoint identifiers that do
not have a previously defined
position.
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 DFI 1 246
136.97 DEFIANCE
>Leg
NDB 1 >021°To 2.3nm
Figure 3-149
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 DFI
136.97
>Leg
NDB 2 >021°To 2.3nm
Figure 3-150
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 MYWPT USR at:
136.97 User Pos L/L?
>Leg User Pos R/D?
SUP 0 Present Pos?
Figure 3-151
