3.10.2. THE NAVIGATION 2 (NAV 2) PAGE
The NAV 2 pages in figures 3-114
and 3-115 display the aircraft’s
present position in one of two formats.
The first line is a cyclic field which
allows you to toggle between formats.
When the NAV 2 page is first dis-
played, it defaults to present position
in terms of the radial and distance
from a nearby VOR. You can change
the reference waypoint from the near-
by VOR to any waypoint.
To change the NAV 2 page present position reference waypoint:
1. With the NAV 2 page on the
radial and distance from a
reference waypoint format, turn
on the cursor (
B
) and move it to
the Ref: field (figure 3-116).
2. Use the right inner and outer knobs to enter the waypoint you
wish to use as a reference.
3. Press
F
. The waypoint page for the identifier just entered will
be displayed.
4. If this is the waypoint you intend-
ed, press
F again. The display
will return to the NAV 2 page
(figure 3-117).
NOTE: If you change the reference waypoint, change to a page
other than the NAV 2 page, then turn back to the NAV 2 page, the
reference waypoint will revert back to a nearby VOR.
By turning on the cursor ( B ) over the first line and pressing E ,
you can change to the latitude and longitude format.
Basic GPS Operation
3-38 Effective Date 5/95 006-08789-0000 Rev 0
Basic GPS Operation
Chapter 3
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg Ref:
KMKC
NAV 2 219°Fr 22.2nm
Figure 3-117
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg N 38°53.74'
NAV 2 W 94°53.39'
Figure 3-114
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg Ref: OJC
NAV 2 310°Fr 9.5nm
Figure 3-115
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg Ref:
OJC
CRSR 346°Fr 28.6nm
Figure 3-116
