3.10.3. THE NAVIGATION 3 (NAV 3) PAGE
The Navigation (NAV) 3 page shows
you several important times pertain-
ing to your flight (figure 3-118).
Line 1: The current system time
zone and time. The time zone may
be changed by turning the cursor (
B
) on over it and turning the
right inner knob. All times shown on the NAV 3 page are in terms of
the system time zone (except for the flight time, which is an elapsed
time).
Line 2: The time of departure. This is the time when a valid ground-
speed was first greater than 30 knots (typically during takeoff).
Line 3: Estimated time of arrival at your destination. If the active
waypoint is not part of the active flight plan, the active waypoint will
be the destination. Otherwise, the last waypoint in your active flight
plan will be the destination.
Line 4: The elapsed flight time, which will be the hours and minutes
since the departure time.
3.10.4. THE NAVIGATION 4 (NAV 4) PAGE
The Navigation (NAV) 4 page (figure
3-119) shows some supplemental
navigation data.
Line 1: The active waypoint or leg,
just like the NAV 1 page.
Line 2: The present desired track (Dtk). This is the great circle
course between two waypoints. Any CDI or HSI driven by the KLX
135A, including the CDI displayed on the NAV 1 page, is referenced
to this desired track. You may wish to look at the navigation terminol-
ogy diagram in Appendix A at this time if you are unfamiliar with
terms like desired track and actual track.
NOTE: If the KLX 135A is in the OBS mode, the selected course
(Obs) is displayed instead of the desired track on the NAV 4 page.
KLX 135A Pilot’s Guide Basic GPS Operation
3-39 Effective Date 5/95 006-08789-0000 Rev 0
Basic GPS Operation
Chapter 3
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 Time CDT 1605
136.97 Depart 1343
>Leg ETA KIXD 1710
NAV 3 Flight 2:22
Figure 3-118
118.00 KICT ∆ KMCI
136.97 Dtk 051°
>Leg Track 046°
NAV 4 Brg 050°
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
Figure 3-119
