BendixKing KLX 135A - Pilots Guide - Manual (Page 57)

4. Turn the right inner knob to select either HRD or ANY. If ANY is
chosen, then both hard and soft surface runways meeting the
required runway length will be included in the nearest airport list.
If HRD is chosen, then only hard surface runways will be includ-
ed. Hard surface runways include concrete, asphalt, pavement,
tarmac, brick, bitumen, and sealed. Soft surface runways include
turf, gravel, clay, sand, dirt, ice, steel matting, shale, and snow.
For example, if the minimum runway criteria selected is 2200 feet in
length and HRD surface, then only airports having a hard surface
runway at least 2200 feet in length will be displayed in the nearest air-
port list.
3.8.1.2 Continuous Display of Nearest Airport
When the nearest airport page is initially displayed, “1” is displayed in
the upper right hand corner of the page to designate this airport as
the nearest airport. However, if you continue to fly along your flight
plan with this page selected, the same airport will be displayed and
its position in the nearest airport list will change from 1 to 2, 3, 4 ... 9
until finally it won’t be in the nearest airport list at all. The reason for
this is that in the event of an actual emergency once you have
determined which airport you are heading for, you don’t want the
nearest airport list to update while you are maneuvering or looking up
data on the other airport pages for that airport.
There may be times, however, when you’re flying over “unfriendly”
terrain when you wish to always have the nearest airport displayed
on the screen.
To display the nearest airport continuously:
1. Display the nearest airport page by pressing
C
,
F
, and
F
again.
2. Turn on the cursor ( B ).
3. Rotate the right outer knob
clockwise to position the cursor
over “1” (figure 3-87). As long as
the cursor is left in this position,
this page will update so that the
nearest airport is always shown
as the flight progresses.
Basic GPS Operation
3-28 Effective Date 5/95 006-08789-0000 Rev 0
Basic GPS Operation
Chapter 3
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 KPAO 1 1370ft
136.97 PALO ALTO-S CL
>Leg 2500ft HRD L
CRSR >126°To 1.2nm
Figure 3-87
