STEP 10
Place the Ladder Stop (A) on top of the Cross-Member (B)
and install the 5/16-18 x 2-1/2" Fastener (Flat Hd. Screw).

(A)

(B)

5/16-18 x 2-1/2"
Flat Hd. Screw

5/16" Flat
Washer

5/16-18 Nylon
Lock Nut

8
