background image

- 17 -

Material

Material

Matériau

Gehäuse

Housing

Boîtier

PBT

Ankerplatte

Anchor plate

Plaque de maintien

Stahl vernickelt/nickel-plated
steel/acier nickelé

Bodenplatte

Base plate

Plaque support

Anticorodal, hart eloxiert

/Anti-

corodal, hard anodised/Anti-
corodal, anodisé dur No.
570600, 570601, 570602
Edelstahl 1.4301/Stainless
steel 1.4301/Acier fin 1.4301
No. 570630

Betätiger

Actuator

Actionneur

Anticorodal, hart eloxiert

/Anti-

corodal, hard anodised/Anti-
corodal, anodisé dur No.
570600, 570601, 570602
Edelstahl 1.4301/Stainless
steel 1.4301/Acier fin 1.4301
No. 570630

Abmessungen siehe Abbildung

Dimensions, see graphic

Dimensions, voir l'illustration

Gewicht

Weight

Poids

Sensor

Sensor

Capteur

1.148 g No. 570600, 570601,
570602
1.470 g No. 570630

Betätiger

Actuator

Actionneur

1.023 g No. 570630
599 g No. 570600, 570601,
570602

Sicherheitstechnische Kennda-
ten

Safety-related characteristic
data

Caractéristiques techniques de
sécurité

PL nach EN ISO 13849-1: 2006

PL in accordance with EN ISO
13849-1: 2006

PL selon EN ISO 13849-1: 2006

PL e (Cat. 4)

Kategorie nach EN 954-1

Category in accordance with EN
954-1

Catégorie selon EN 954-1

Cat. 4

SIL CL nach EN IEC 62061

SIL CL in accordance with EN IEC
62061

SIL CL selon EN IEC 62061

SIL CL 3

PFH nach EN IEC 62061

PFH in accordance with EN IEC
62061

PFH selon EN IEC 62061

3,29E-09

SIL nach IEC 61511

SIL in accordance with IEC 61511

SIL selon IEC 61511

SIL 3

PFD nach IEC 61511

PFD in accordance with IEC 61511 PFD selon IEC 61511

1,72E-04

T

M

[Jahr] nach EN ISO 13849-1:

2006

T

M

[year] in accordance with EN

ISO 13849-1: 2006

T

M

[année] selon EN ISO 13849-1:

2006

20

585241611

Es gelten die 2008-04 aktuellen Ausgaben der
Normen.

The standards current on 2008-04 apply.

Les versions actuelles 2008-04 des normes
s'appliquent.

Mechanische Daten

Mechanical data

Données mécaniques
