B&C Technologies SA Series Industrial User Manual
Page 53
OPERATING INSTRUCTIONS
4-31
Machine
Cylinder Dia
0.4 G
0.8 G
1.0 G
1.5 G
3.0 G
50 G 150 G 320 G
350 G
HE-30
0.612 m
34.2
48.4
54.1
66.2
93.7
382.4
662.4
967.5
1011.8
SP/HP/HE-40
0.680 m
32.4
45.9
51.3
62.8
88.9
362.8
628.4
917.5
959.9
SP/HP/HE-60
0.790 m
30.1
42.6
47.6
58.3
82.4
336.6
583.0
851.5
890.6
HE-80
0.924 m
27.8
39.4
44.0
53.9
76.2
311.2
539.1
797.4
823.4
SP/HP-100
0.940 m
27.6
39.0
43.6
53.4
75.6
308.6
534.5
780.6
816.4
SI-110
0.940 m
27.6
39.0
43.6
53.4
75.6
308.6
534.5
780.6
816.4
SI-135
1.092 m
25.6
36.2
40.5
49.6
70.1
286.3
495.9
724.3
757.5
SI-200
1.169 m
24.7
35.0
39.1
47.9
67.8
276.7
479.3
700.0
732.1
SI-275
1.321 m
23.3
32.9
36.8
45.1
63.8
260.3
450.9
658.5
688.7
SI-300
1.321 m
23.3
32.9
36.8
45.1
63.8
260.3
450.9
658.5
688.7
SA-475
1.629 m
21.0
29.6
33.1
40.6
57.4
234.4
406.0
593.0
620.2
Machine
Cylinder Dia
50 G
75 G 100 G 125 G 150 G 175 G 200 G 225 G
250 G
HE-30
0.612 m
382.4
468.4
540.8
604.7
662.4
715.5
764.9
811.2
855.1
SP/HP/HE-40
0.680 m
362.8
444.3
513.1
573.6
628.4
678.7
725.6
769.6
811.2
SP/HP/HE-60
0.790 m
336.6
412.2
476.0
532.2
583.0
629.7
673.2
714.0
752.7
HE-80
0.924 m
311.2
381.2
440.2
492.1
539.1
582.3
622.5
660.2
695.9
SP/HP-100
0.940 m
308.6
377.9
436.4
487.9
534.5
577.3
617.1
654.6
690.0
SI-110
0.940 m
308.6
377.9
436.4
487.9
534.5
577.3
617.1
654.6
690.0
SI-135
1.092 m
286.3
350.6
404.9
452.7
495.9
535.6
572.6
607.3
640.2
SI-200
1.169 m
276.7
338.9
391.3
437.5
479.3
517.7
553.4
587.0
618.7
SI-275
1.321 m
260.3
318.8
368.1
411.6
450.9
487.0
520.6
552.2
582.0
SI-300
1.321 m
260.3
318.8
368.1
411.6
450.9
487.0
520.6
552.2
582.0
SA-475
1.629 m
234.4
287.1
331.5
370.6
406.0
438.5
468.8
497.2
524.1
Machine
Cylinder Dia
275 G 300 G 325 G 350 G
HE-30
0.612 m
896.9
936.7
975.0 1011.8
SP/HP/HE-40
0.680 m
850.8
888.7
925.0
959.9
SP/HP/HE-60
0.790 m
789.4
824.5
858.2
890.6
HE-80
0.924 m
729.9
762.4
793.5
823.4
SP/HP-100
0.940 m
723.7
755.8
786.7
816.4
SI-110
0.940 m
723.7
755.8
786.7
816.4
SI-135
1.092 m
671.4
701.3
729.9
757.5
SI-200
1.169 m
648.9
677.8
705.5
732.1
SI-275
1.321 m
610.5
637.6
663.6
688.7
SI-300
1.321 m
610.5
637.6
663.6
688.7
SA-475
1.629 m
549.7
574.2
597.6
620.2
WC03 PROGRAM SPEEDS IN RPM FROM G-FORCE POINTS
C. Oswald 01/26/05, rev. C
EXTRAC RPM TO G – FORCE
