Notes on Motor Programming
There are a number of different moles available for motor programming:
1. Forwards – Pause k – Backwards
2. Forwards – Pause
3. Forwards
4. Pause – Backwards
5. Backwards
The minimum pause time that can be programmed between forward and backwards is 2 seconds.
Cylinder speed is programmed during cycle programming. In this mode, step can be programmed
with different values if desired.
T. FORWARD = XXs
T. PAUSE = XXs
T. BACKWARDS = XXs
T. FORWARD = XXs
T. PAUSE = XXs
T. FORWARD = XXs
T. PAUSE = SO
T. FORWARD = SO
T. PAUSE = XXs
T. BACKWARDS = XXs
T. FORWARD = SO
T. PAUSE = SO
T. BACKWARDS = XXs
