Verifying the Update
Confirm upgrade installation
Once the CPU and Central Station have restarted, the system map screen should be
viewable on the display.
To confirm upgrade success:
1. On the Central Station screen:
a. Move the pointer into the gray area in the upper right hand corner of the screen.
b. Hold down the
◆
key on the keyboard and press the right trackball/mouse key.
2. When the System Menu appears in the upper right corner, click Revision.
3. The bottom border of the map screen will be replaced by a splash window similar to
the following.
4. The Software Version should now display as 7.01.01, and the splash screen will
automatically disappear after a few moments.
Note If the system does not display the system map or the software appears to quit
during startup, contact Welch Allyn Technical Support for immediate assistance.
