Operator Manual Corival
8
2 Main menu
When the ergometer is started after pressing the confirmation button ( ) you enter the MAIN
MENU. The following submenus are selectable from the main menu:
TERMINAL
MANUAL
ANALOG
SYSTEM PARAMETER
Use the arrow keys▲ ♥ to scroll through the menus. Press the ( ) button to select a menu.
Keeping the ( ) pressed for a few seconds allows you to go up one or more menu levels,
wherever you are in the menu. The complete menu structure is shown below. In front of each
menu the level depth is indicated.
0. MAIN MENU
1. ANALOG
1. MANUAL
1. TERMINAL
1. SYSTEM PARAMETER
2. SET DISPLAY
3. POWER
3. RPM
3. HEARTRATE
3. TORQUE
3. TIMER
3. DISTANCE
2. SET P-SLOPE
2. SET MODE
3. HYPERBOLIC
3. HR CONTROLLED
3. LINEAR
3. FIXED TORQUE
2. SETTINGS
3. DEFAULT STARTMENU
3. KEYBOARD ON/OFF
3. TEST FUNCTIONS
3. P IN/OUT ANALOG
3. ECG TRIGGER
3. TC_BYTES
3. RS232 PROTOCOL
3. LANGUAGE
3. DEVICE NO
