Operator Manual Corival
16
Then the main menu appears:
The menu displayed in capitals can be selected. As extra reminder the first 4 letters of the
selectable mode are showed above the confirmation button. With the ▲ ♥ keys you can scroll
through the other menus and select SYSTEM PARAMETERS, MANUAL, ANALOG or
PROTOCOL. With the right ( ) confirmation button the menu in capital can be selected. The
left ( ) escape button is used to go back one level in the menu structure.
The ergometer is now ready for use. If nothing appears in the display(s), check whether the
power cord and the control unit have been properly connected or contact your supplier.
B.3.1 Menu structure programmable control unit
0. MAIN MENU
1. ANALOG
1. MANUAL
1. TERMINAL
1. SYSTEM PARAMETER
2. SET DISPLAY
3. POWER
3. RPM
3. HEARTRATE
3. TORQUE
3. TIMER
3. DISTANCE
3. TARGET HR*
3. ENERGY*
2. SET P-SLOPE
2. SET MODE
3. HYPERBOLIC
3. HR CONTROLLED
3. LINEAR
3. FIXED TORQUE
2. SETTINGS
3. DEFAULT STARTMENU
3. P IN/OUT ANALOG
3. CONTRAST
3. ECG TRIGGER
3. TC_BYTES
3. RS232 PROTOCOL
3. LANGUAGE
LODE ERGOMETER
BPM initialized
system parameter
TERMINAL
manual
Term
