Operator Manual Corival
17
3. DEVICE NO
1. PROTOCOL*
2. PROTOCOL EDIT *
2. PROTOCOL RUN *
2. PROTOCOL DELETE *
Compared to the standard version the *menus are added.
B.3.2 Manual menu
Selecting the manual mode will show you (default) the following display at the programmable
control panel:
BPM* is displayed when this option is available, otherwise another MENU possibility is
active. With the ▲ ♥ keys you can increase or decrease the parameter of the selected mode.
In the middle the adjustable parameter is shown, f.i. the load P (to be set with SYSTEM
PARAMETERS> SET MODE)
B.3.3 Analog menu
Selecting the ANALOG menu will show the following screen at the programmable panel:
Notice:
θ = 0/m*
Only displayed if BPM option is being installed!
The ergometer is now ready for external control with an analog signal as previously
described. See for more information about analog control the user guide (only available in
English) supplied with the ergometer.
B.3.4 Terminal menu
Selecting the TERMINAL menu will show the following screen at the programmable panel:
Notice:
θ = 0/m*
Only displayed if BPM option is being installed!
ANALOG
P = 0W 0 rpm
θ = 0/m*
esc esc
TERMINAL P
P = 0W 0 rpm
θ = 0/m*
esc esc
MANUAL P
P = 0W 0 rpm
θ = 0/m*
esc P BPM*
