Operator Manual
Corival
21
EOS
End Of Stage; automatic measurement at every end of the exercise step with
the possibility to program the measurement time before the end of the stage.
Recovery time If you have programmed automatic BP measurement in the protocol, you get
the possibility to program the repeat time of the BP measurement during the recovery stage:
After the programming of the BPM the menu PROTOCOL will appear again. You can RUN
EDIT or DELETE one of the protocols now.
B.3.7.2
Example Programming Protocol
For the purpose of clarification we will program a demonstration protocol with all
possibilities. Execute the following steps to get into the programming mode.
1.
Select PROTOCOL in the MAIN MENU, confirm ( )
2.
Select PROTOCOL edit, confirm ( )
3.
Select New, confirm ( )
4.
Give a protocol name: test
5.
With the ▲ ♥ keys you can scroll through the alphabet confirm, use OK ( ) to go to
the next position
6.
The program screen appears, the underscore showing the programming parameter:
7.
Confirm the S with ( ), use the ▲ key to decrease the workload to 10 watt.
8.
Press the confirmation button OK until you reach the following screen. Adjust time dt
to 60 seconds using the ▲ ♥ keys.
9.
Select T with the ▲ ♥ keys and adjust the Torque to 10 Nm and the duration to 30
seconds with
the same keys.
Press the
confirmation
button.
10.
Select L with the ▲ ♥ keys and confirm the constant π =0.041, change the duration to
10 seconds. Press the confirmation button.
11.
Select H with the ▲ ♥ keys and change the heart rate in 120/m for a duration of 180
seconds, press the confirmation button.
12.
Select P with the ▲ ♥ keys and change the Workload to 150 in duration of 300
seconds, press the confirmation button.
13.
Select P with the ▲ ♥ keys and change the Workload to minus 60 in 60 seconds, press
the confirmation button.
test
Torq P= 10W t=01:00
2T T= 10Nm dt=030s
esc next
test
Step P= 0W t=00:00
1S dP=+050W dt=060s
esc next
