Operator Manual Corival
18
The ergometer is now ready for digital external control. For more information about digital
external control using the RS 232 serial port see the user guide supplied with the ergometer.
B.3.5 System parameters menu
In the SYSTEM PARAMETERS different ergometry specific settings can be carried out as
described previously in the standard manual. On the programmable control panel you can
select the desired menu:
The menu displayed in capitals and repeated with an abbreviation under the confirmation
button ( ) is the one which can be activated. Selecting one of these menus will show you a
more extended display then described previously in this manual. As you can see with the
example of SET DISPLAY:
Where the function POWER is the same as described previously in this manual (power
indication on or off), the button SYS will bring you back to the system parameters menu.
With the ▲ ♥ keys you can select the power indication to be ON or OFF, and NEXT will
bring you to the next item of the SET DISPLAY menu. Beside the parameters RPM, HEART
RATE, TORQUE, TIMER and DISTANCE two more are parameters are added: TARGET
HEART RATE and ENERGY.
Selecting the target HR parameter will show you the target heart rate programmed in the heart
rate controlled protocol beside the actual heart rate. For instance:
Selecting the energy parameter will show you the total amount of mechanical energy
delivered by the test subject going into the ergometer in the form of mechanical motion,
during the exercise test.
Instead of 2 items you can show 4 items out of your selection at once, they will scroll in
groups of 2. When you select 4 parameters, there will be no scrolling but a fixation on the
set p slope
SET DISPLAY
settings
POWER
On
Esc off on next
2 t=00:48 =01:12
P= 23 W 61 rpm
θ= 91/min tθ=100/min
recovery ok
