Welch Allyn CP 200 12-Lead Resting Electrocardiograph - User Manual - Manual (Page 75)

Directions for Use Chapter 6 Performing Administrative Tasks 71
To Print, Send, or Delete Saved Tests
1. Press the Menu key .
2. Choose Test Directory.
If prompted to log in, enter your user ID and password.
The following screen appears.
Figure 47. Test Directory “Search” Screen
3. (Optional) Press Print Directory to print the contents of the test directory.
4. Select or fill in the search criteria, as explained in Figure 47 .
To clear all entries, press Clear.
5. Press Search.
If any saved tests match your criteria, the Search Results screen appears.
6. Select the desired tests.
• To select a continguous group of tests, press and hold the Shift key while
pressing an arrow key.
• To select an individual test, press an arrow key.
• To select all tests, press Ctrl-A.
7. Press the desired softkey.
• Back — returns to the search screen so you can create a new search.
• Delete — deletes the selected test(s).
• Print — prints the selected test(s).
• Send — sends the selected test(s) to your choice:
Memory Card
An SD memory card or removable USB storage device must be in place.
Workstation
Either wireless communications must be configured or a USB cable must
connect a CardioPerfect workstation to the electrocardiograph’s Com port B
(
).
Search
Unprinted Tests
Unconfirmed Tests
Unsent Tests
All Tests
Date From
Date To
Patient ID
Last Name
9:17AM Oct 16 08
Print
Directory
Search
Use these criteria to find and perform actions
on a batch of tests.
Use these criteria (partial or complete) to find
and perform actions on a single test.
Clear
ˆ
ˆ
ˆ
ˆ
/ / MM / DD / YYYY
/ / MM / DD / YYYY
