Directions for Use Chapter 4 Reviewing the ECG Settings 39
About Auto ECG Reports
An Auto ECG is a report of ECG data in one of two user-defined formats: Auto Report 1 or
Auto Report 2. For an example, see
Figure 25 . To learn how to set up or interpret a report,
see the references on page 40 .
Figure 25. Auto Report Example — 3x4 +3R Lead Arrangement
Note If you want a second predefined format to be available, enable Auto Report 2.
To learn how, see
“Reviewing the Miscellaneous ECG Settings” on page 48.
E. 3 rows, 4 columns
F. Rhythm leads
A. Patient data B. ECG measurements C. Interpretation (optional)
L. Frequency range N. Paper speed
K. AC filter
J. Date and time
H. Device ID
G. Software version
D. Report status label
O. Calibration
pulse M Gain
I. Practice ID
