46 Chapter 4 Reviewing the ECG Settings Welch Allyn CP 200 Electrocardiograph
Reviewing the Auto Report Settings
1. Press the Menu key .
2. Choose ECG Settings > Auto Report Settings.
The following screen appears.
Figure 29. “Auto Report Settings” Screen for ECG Settings
3. Change any desired settings.
Setting Description
Baseline Centering On or off. When on, aligns the isolectric line of all leads.
Lead Timing Simultaneous or sequential. “Simultaneous” prints ECG data that was captured
simultaneously for all lead groups. “Sequential” prints ECG data that was captured at
sequential intervals for each lead group in turn.
Auto Report 2 On or off. When on, a second predefined report format is available.
Artifact Report On or off. When on, the electrocardiograph automatically prints an artifact report with
the Auto ECG report whenever artifact is detected and you override the “Waiting for
10 seconds of quality data” message. This report, a 12x1 format with all filters
disabled, shows the leads with artifact so that you can remedy the problem. (The
normal Auto ECG report, with filters enabled, might mask some of the artifact issues.)
QTc Method Bazett or Hodges. Computation method of correcting the waveform’s QT interval
based on the heart rate. The corrected number, expressed in milliseconds, is called
the QTc interval. This setting affects only the QTc interval displayed in the ECG
measurements portion of the ECG report.
Auto Report Settings
1 Baseline Centering
2 Lead Timing
3 Auto Report 2
4 Artifact Report
5 QTc Method
0 Previous Menu
9:17AM Oct 16 08
