Directions for Use
Chapter 5 Performing ECG Tests
57
Recording a Normal Auto ECG
For a normal Auto ECG, you enter patient data and do other optional tasks before printing,
as shown in
To Record a Normal Auto ECG
1.
Press the Auto ECG key
quickly.
Do not hold it down, or a stat ECG would begin.
2.
If prompted, choose Auto Report 1 or Auto Report 2.
The following screen appears.
Figure 37. “Enter New Patient” Screen
3.
Enter or recall the patient data.
•
If you are using a bar code scanner, scan the patient’s bar code. The patient ID
appears on the screen.
•
If you want to enter the data, fill in the fields.
•
If you want to recall saved patient data, go to
“Recalling Saved Patient Data”
When finished, press the desired softkey:
Clear deletes the entered data and returns to the Patient ID field.
Done accepts the entered data and goes to the Auto ECG Acquisition
screen. See
For details about these data fields—
including how to choose which fields
display and print—see
Patient Data Fields Available for Auto
Reports”
Enter New Patient
Search
Schedule
Clear
Done
9:17AM Oct 16 08
Patient ID
Last Name
First Name
Birth Date
Weight
Height
Gender
/
/
MM / DD / YYYY
ft.
in.
lb.
