40 Chapter 4 Reviewing the ECG Settings Welch Allyn CP 200 Electrocardiograph
Item (in Figure 25 on page 39) Description
A. Patient data See “Reviewing the Patient Data Fields Available for Auto Reports” on page 44.
B. ECG measurements Standard.
C. Interpretation (optional) See “Reviewing the Interpretation and Copy Settings for Auto Reports” on
page 43.
D. Report status label See “Reviewing the Interpretation and Copy Settings for Auto Reports” on
page 43.
E. 3 rows, 4 columns See “Reviewing the Format Settings for Auto Reports” on page 41.
F. Rhythm leads See “Reviewing the Format Settings for Auto Reports” on page 41.
G. Software version See also “Reviewing the Device Information” on page 31.
H. Device ID See “Device ID” on page 29.
I. Practice ID See “Practice ID” on page 29.
J. Date and time See “Set Date/Time” on page 29.
K. AC filter See “Mains Filter” on page 48.
L. Frequency range Lower limit: baseline filter on = 0.5, off = 0.3
Upper limit: muscle filter on = 35, off = 150
See
“Baseline Filter” on page 68 and “Muscle Filter” on page 68.
M Gain See “Gain” on page 68.
N. Paper speed See “Speed” on page 68.
O. Calibration pulse Amplitude reference — represents the current height of a one-millivolt signal.
Is adjusted for the selected gain:
5 mm/mV = 0.5 x
10 mm/mV = 1 x
20 mm/mV = 2 x
