1. Select the appropriate-sized eartip.
2. Push and slightly twist the eartip onto the probe tube.

Ensure that the eartip is fully seated on the probe. There should be no gaps between

the eartip and the collar of the probe head.

3. To remove the eartip, grasp the probe tube gently at the base and slightly twist it

while pulling the eartip off of the probe tube.
Grasping the base of the probe tube will prevent it from being inadvertently pulled

out of the probe head along with the eartip.

Probe holder

The probe holder is a receptacle attached to the HDMI cable that secures the probe

when you are not using the screener. Placing the probe into the probe holder protects

the probe head. Welch Allyn recommends that you insert the probe into the probe holder

when the screener is not in use, such as when it is on a counter top or table, or when

the screener is placed in the screener cradle.

Attach the probe holder

1. Place the probe holder near the end of the probe cable at the HDMI connector end.

2. Gently press the probe cable into the probe holder close to the point of the probe

head.

Directions for use

Setup 17
