When these steps are completed, the Model 400 is fully
operational and able to monitor temperature, high sound, AC
power failure and battery backup condition; it can also be called
on the telephone for a Status Report or be used for listening to on-
site sounds from any remote location. Now, the unit is ready for
programming.
3.3 Quick-Start Programming Steps
Step 1: Set Configuration of Zones
The Model 400 will scan the 4 external zones and determine
if they are N.O. (normally open), N.C. (normally closed), or
Temperature. If external sensors are added, make sure they are
in their normal positions before proceeding—refer to Chapter 5,
Section 5.1.
1. Press STANDBY to place the Model 400 in Standby
mode.
RUN
STANDBY
2. If you have external sensors available, wire the sensors to the
zones on the back of the Model 400 (see Chapter 2,
Section 2.10). Otherwise, skip this step and move to step 3.
3. Press RUN. The System On light glows when the Model 400
returns to Run mode.
RUN
STANDBY
4. Press SET.
SET
5. Press CONFIGURE.
CONFIG
6. The Model 400 will audibly recite the new configuration for
each of the four zones, responding with “normally open”,
“normally closed”, or “Temperature.” If a zone is unused, it
is treated as normally open.
