Page 45
45
Setup
ctrl io
5
Control inputs/outputs
(Display designation of this menu level: 5)
ctr inp
Control inputs
For YDO01M-232CO; Option A1
8.4.
Function for external control inputs (TTL)
8.4.1*
Trigger p key function
8.4.2
Trigger p key (> 2 sec) function
8.4.3
Trigger ) key function
8.4.4
Trigger ) key (> 2 sec) function
8.4.5
Trigger k key function
8.4.7
Trigger O key function
Midrics 2 only
8.4.8
Combined zero/tare function
8.4.9
Trigger ( key function
8.4.10
Trigger p key function
8.4.11
Trigger c key function
Midrics 2 only
8.4.12
Trigger I key function
Midrics 2 only
For YDO01M-IO; Option A5
8.17.
External input 1
8.17.1
Trigger p key function
8.17.12
Trigger I key function
Midrics 2 only
8.18.
External input 2
8.26.1
Trigger p key function
8.18.12
Trigger I key function
Midrics 2 only
8.19.
External input 3
8.27.1
Trigger p key function
8.19.12
Trigger I key function
Midrics 2 only
8.20.
External input 4
8.28.1
Trigger p key function
8.20.12
Trigger I key function
Midrics 2 only
8.21.
External input 5
8.21.1
Trigger p key function
8.21.12
Trigger I key function
Midrics 2 only
ctr out
Control outputs
For YDO01M-IO; Option A5
8.24.
External output 1
8.24.1*
Weighing instrument ready to operate
8.24.2
Weighing instrument stable
8.24.3
Weighing instrument overflow (“H")
8.24.4
Weighing instrument underflow (“L")
8.24.5
Value in tare memory
8.24.8
Lighter
Midrics 2 only
8.24.9
Equal
Midrics 2 only
8.24.10
Heavier
Midrics 2 only
8.24.11
Set
8.25.
External output 2
8.25.1
Weighing instrument ready to operate
8.25.11
Set
8.26.
External output 3
8.26.1
Weighing instrument ready to operate
8.26.11
Set
8.27.
External output 4
8.27.1
Weighing instrument ready to operate
8.27.11
Set
8.28.
External output 5
8.28.1
Weighing instrument ready to operate
8.28.11
Set
