Setup
unicom
3
Interface port 2 (Optional)
(Display designation of this menu level: 3)
off
*
Off
datprot
Data protocol
sbi
*
SBI: standard version
5.1. through 9.1.
Numeric menu as for COM1
bpi-232
XBPI-232
bpi-485
XBPI-485
0 to 31
Network address: From 0 to 31 inclusive
sma
SMA interface function
5.1. through 5.6.
Numeric menu as for COM1
ETHEr
Ethernet
src-ip
Source IP: 192.168.0.1*
src.name
Source name (16 characters maximum)
lis.port
Listen on port: 49155*
subnet
Subnet mask: 255.255.255.0*
gate-ip
Gateway IP: 0.0.0.0*
dest-ip
Destination IP: 0.0.0.0*
dest.por
Destination port: 49155*
Protocol
TCP*
UDP
Mode
SBI (server)*
6.1.
Manual output/automatic
6.1.1
Manual without stability
6.1.2 *
Manual after stability
6.1.4
Automatic without stability
6.1.5
Automatic with stability
6.1.7
Data record for computer printout
7.2.
Data output: line format for printout
7.2.1
For raw data: 16 characters
7.2.2*
For other apps.: 22 characters
SBI-C/S
6.1.
Manual output/automatic
6.1.1
Manual without stability
6.1.2 *
Manual after stability
6.1.4
Automatic without stability
6.1.5
Automatic with stability
6.1.7
Data record for computer printout
6.3.
Time-dependent automatic data output
6.3.1 *
1 display update
6.3.2
2 display updates
6.3.4
10 display updates
6.3.7
100 display updates
7.2.
Data output: line format for printout
7.2.1
For raw data: 16 characters
